HIKMICRO Lynx 3.0 LQ35L 35mm LRF Thermal Imaging Monocular Black
£1,699.99
Product Code: HM-LQ35L3.0
HIKMICRO Lynx 3.0 LQ35L 35mm LRF Thermal Imaging Monocular Black
£1,699.99
Product Code: HM-LQ35L3.0
The Lynx 3.0, redefining entry-level thermal imagers. The HIKMICRO LQ35 delivers premium long-range detection, advanced AI image processing, and silent operation; built for professionals who demand precision, endurance, and exceptional image performance.
Please select a size:
Stock Alert
Please alert me via email when this product is back in stock.
The Lynx 3.0 , redefining entry-level thermal imagers.
The HIKMICRO Lynx 3.0 LQ35 represents the pinnacle of thermal monocular performance for serious professionals. Featuring a 640x512 thermal detector and a 35mm F1.0 lens, it delivers 1.9x base magnification out to 15.2x, a 12.5°×7.5° field of view, and a detection range of up to 1800 metres, making it the ultimate tool for long-range observation.
For the First time the LQ35 introduces an integrated Laser Range Finder (LRF) with a 905 nm wavelength and a maximum measuring range of 1000m, providing precise distance measurement directly within the thermal imaging system
Incorporating AI-driven Image Pro 3.0 and Zoom Pro algorithms, the LQ35 offers superior image fidelity and consistency across challenging conditions. The HSIS shutterless technology enables smooth, silent operation for continuous, distraction-free imaging.
At 354.5 grams, the LQ35 remains portable yet robust. A replaceable 18650 battery provides up to 4.5 hours of operation at -20°C, ensuring dependable field endurance. Ideal for hunting, security, or professional surveillance, it delivers unmatched clarity and control.
- Max. Resolution: 640 × 512
- Frame Rate: 50 Hz
- Pixel Interval: 12 μm
- Response Waveband: 8 μm – 14 μm
- NETD: < 15 mK (@25°C), F#=1.0
- Lens (Focal Length): 35 mm, f1.0
- Focus Mode: Focus Ring
- Detection Range: 1800 m
- Min. Focusing Distance: 3.5 m
- Magnification: 1.9× – 15.2× (8×)
- Field of View (H × V): 12.5° × 7.5° / 21.9 m × 13.2 m @100 m
- Display: 1920 × 1080, 0.49 in, AMOLED
- Palettes: Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
- Exit Pupil: 6 mm
- Eye Relief: 20 mm
- Diopter (Range): -5D to +3D
- Brightness Adjustment: Yes
- Tone Adjustment: Cold, Warm
- Contrast Adjustment: Yes
- Zoom Pro: Yes
- HSIS (HIKMICRO Shutterless Image System): Yes
- Image Pro 3.0: Yes
- Record Video: Yes
- Capture Snapshot: Yes
- Audio Recording: Yes
- Standby Mode: Yes
- Built-in Memory: 64 GB EMMC
- PIP: Yes
- Hotspot: 2.4 GHz / 5 GHz Wi-Fi
- Hot Track: Yes
- Distance Measurement: Yes
- Local Album: Yes
- Battery Type: Replaceable & Rechargeable Li-ion 18650
- Battery Operating Time: 5-hour continuous (@25°C), 4.5-hour continuous (@-20°C)
- Type-C Power Supply: 5V DC, 2A
- External Power Supply: Supported, Direct Charging Supported
- Safety Class for Laser: Class 1
- Wavelength: 905 nm
- Max Measuring Range: 1000 m
- Min. Measuring Range: 10 m
- Measurement Accuracy: ±1 m
- Protection Level: IP67
- Dimension: 169.6 × 53.6 × 49.5 mm
- Weight: 354.5 g (with battery)
- Working Temperature: -30°C to 45°C (-22°F to 113°F)
- Humidity: ≤ 90%
